ER7212PC Omada 3-in-1 Gigabit VPN Gateway
23.307,79 ₺
Simplify Networking Begins with the 3-in-1 Integrated Gateway
The ER7212PC is a VPN gateway that integrates 8x PoE+ ports and centralized management capability. Connect to Omada access points and PoE-supported devices with ease.
All you need is an ER7212PC to get Gigabit Internet access.
DPI Integration: Enhancing Application and Traffic Management
Fanless Desing for Heat Dissipation and Silent Operation
DPI Integration: Enhancing Application and Traffic Management
Fanless Desing for Heat Dissipation and Silent Operation
*PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors.
**The SFP port of ER7212PC does not support direct-attach cable connection, including SM5220-1M (TL-SM5220-1M), SM5220-3M (TL-SM5220-3M), etc.
§ER7212PC can work as a VPN client and can connect with up to 10 VPN servers.
| GÜVENLİK | |
|---|---|
| DPI | Deep Packet Inspection Support 2421 type Applications Max Throughput (Upload / Download) 942.7Mbps/937.3Mbps |
| Access Control | Source/Destination IP Based Access Control |
| Filtreleme | URL Filtering |
| ARP Denetleme | Sending GARP Packets IP-MAC Binding |
| Saldırı Koruması | TCP/UDP/ICMP Flood Defense Block TCP Scan (Stealth FIN/Xmas/Null) Block Ping from WAN |
| DONANIM ÖZELLİKLERİ | |
|---|---|
| Standartlar ve Protokoller | IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, SNMP |
| Arabirim | • 2 Gigabit SFP WAN/LAN ports** • 1 Gigabit WAN port • 1 Gigabit LAN/WAN port • 8 Gigabit LAN ports |
| Ağ Medyası | 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
| Fan Sayısı | Fanless |
| Buton | Reset Button |
| Güç Kaynağı | 53.5VDC/2.43A Adapter |
| PoE Budget | 8 ports PoE+ output, 110 W PoE Budget |
| Flash | 32Mbit Nor+8GB eMMC |
| DRAM | 2 GB DDR4 |
| LED | PWR, SYS, CLOUD, PoE Max, SFP 1, SFP 2, WAN (Speed, Link/Act), LAN (Speed, Link/Act) |
| Boyutlar ( W X D X H ) | 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) |
| Koruma | 6kV surge protection |
| Muhafaza | Steel |
| Montaj | Desktop/Wall-mount/Rack-mount |
| Maks. Güç Tüketimi | 131 W (110 V/60 Hz) (With 110 W PD connected |
| PERFORMANS | |
|---|---|
| Eşzamanlı Oturum | 50,000 |
| New Sessions /Second | 3,800 |
| NAT (Static IP) | 940.2 Mbps / 947.5 Mbps |
| NAT(DHCP) | 947.8 Mbps / 948.6 Mbps |
| NAT(PPPoE) | 943.1 Mbps / 942.6 Mbps |
| NAT (L2TP) | 898.4 Mbps / 915.8 Mbps |
| NAT (PPTP) | 909.7 Mbps / 912.8 Mbps |
| IPsec VPN Throughput | ESP-SHA1-AES256: 984.7 Mbps, ESP-SHA2-AES256: 990.5 Mbps, ESP-SHA384-AES256: 983.9 Mbps, ESP-SHA512-AES256: 985.8 Mbps |
| OpenVPN | 233.1 Mbps |
| L2TP VPN Throughput | Unencrypted: 1,273.9 Mbps Encrypted: 851.8 Mbps |
| PPTP VPN Throughput | Unencrypted: 1293.5 Mbps Encrypted: 297.1 Mbps |
| 66 Byte Packet Forwarding Rate | 1,453,459 pps / 1,453,459 pps |
| 1,518 Byte Packet forwarding rate | 81,272 pps / 81,272 pps |
| TEMEL FOKSİYONLAR | |
|---|---|
| WAN Bağlantı Türü | Static IP Dynamic IP PPPoE PPTP L2TP |
| MAC Klon | Modify WAN MAC Address |
| DHCP | DHCP Server DHCP Options Customization DHCP Address Reservation Multi-IP Interfaces Multi-Net DHCP |
| IPv6 | StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode |
| VLAN | 802.1Q VLAN |
| IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
| GELİŞMİŞ FONKSİYONLAR | |
|---|---|
| ACL | Source/Destination IP Based ACL Stateful ACL IPv4/IPv6 ACL National Based ACL |
| Gelişmiş Yönlendirme | • Static Routing • Policy Routing |
| Bandwidth Kontrol | IP-based Bandwidth Control |
| Load Balance | • Intelligent Load Balance • Application Optimized Routing • Link Backup • Online Detection |
| NAT | Multi-Net NAT One-to-One NAT Port Forwarding NAT-DMZ FTP/H.323/SIP/IPSec/PPTP ALG UPnP |
| Session Limit | IP-based Session Limit |
| VPN | |
|---|---|
| SSL VPN | - |
| IPsec VPN | 20 IPSec VPN Tunnels LAN-to-LAN, Client-to-LAN Main, Aggressive Negotiation Mode DES, 3DES, AES128, AES192, AES256 Encryption Algorithm IPsec Failover IKE v1/v2 MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm NAT Traversal (NAT-T) Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS) |
| PPTP VPN | PPTP VPN Server PPTP VPN Client (10) 16 Tunnels PPTP with MPPE Encryption |
| L2TP VPN | L2TP VPN Server L2TP VPN Client (10) 16 Tunnels L2TP over IPSec |
| OpenVPN | OpenVPN Server OpenVPN Client (10) 16 OpenVPN Tunnels "Certificate + Account" Mode Full Mode |
| AUTHENTICATION | |
|---|---|
| Web Authentication | No Authentication Simple Password Hotspot (Local User / Voucher/ SMS / Radius) External Radius Sever External Portal Sever |
| YÖNETİM | |
|---|---|
| Omada App | Yes. |
| Centralized Management | Management of up to 2 Omada switches, and 10 Omada access points |
| Cloud Access | Yes. |
| Servis | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization) |
| Bakım | Web Management Interface Remote Management Export & Import Configuration SNMP v1/v2c/v3 Diagnostics (Ping & Traceroute) NTP Synchronize Port Mirroring Syslog Support |
| Zero-Touch Provisioning | - |
| Management Features | • Automatic Device Discovery • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal Configuration • Management of up to 2 Omada switches and 10 Omada access points |
| DİĞERLERİ | |
|---|---|
| Sertifika | CE, FCC, RoHS |
| Paket İçeriği | • ER7212PC • Power Adapter • Power Cord • Quick Installation Guide |
| Sistem Gereksinimleri | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11 MAC OS, NetWare, UNIX or Linux |
| Ortam | Operating Temperature: -5 °C to 45 °C Storage Temperature: -40 °C to 70 °C Operating Humidity: 10% to 90% non-condensing Storage Humidity: 5% to 90% non-condensing |
